FS Series Square Shape Vibrating Sifter ( Vibrating sieve )(Vibrating Screen)
FS Series Square Shape Vibrating Sifter ( Vibrating sieve )(Vibrating Screen)
The machine consists of screen box at material inlet and outlet, vibrator and shock absorber. There are 4-6 sets of flexible rubber shock absorber connected between base and screen box in up-down order. Centrifugal force is generated upon starting the machine. Control shock absorber against amplitude eccentric device correspondingly for best pertormance and material screening process in throwing vibration and loose. It is the ideal choice for pharmaceutical, food, chemical, metallurgy and electronic industries.
Video
Characters and Function
With Bottom, vibrating motor, mesh, clamps, sealing strips(rubber or gel silica), cover.
It absorbs the advanced technology from domestic and overseas, and adopts senior processing technique.
It is a kind of high-precision screening and filtering machine.
The vertical vibrating motor is the vibrating power of machine.
There are two eccentric blocks on the motor's upper and down.
The eccentric blocks make cubic element movement (horizontal ,up-down,and tilting).
By changing the eccentric block's included angle ( the upper and down), the track that material moves on the mesh ,will be changed so that the screening target will be realized.
Technical Parameter
| Model/ Specification |
Power (kw) |
Screen surface inclination |
Voltage (V) |
Screen surface layers |
Mesh sieve |
Dimensions (mm) |
Weight (kg) |
Yield (kg/h) |
| FS0.6×1.5 | 0.4 | 0°~45° | 380V | 1～4 | 6～120 | 1500×700×700 | 550kg | 150～1500 |
| FS0.65×2.0 | 0.4 | 0°~45° | 380V | 1～4 | 6～120 | 2100×750×780 | 650kg | 160～2000 |
Applications
FS series square sieve is my company developed its own new generation sieving equipment, the aircraft with its unique high efficiency, low noise and so welcomed by the majority of users, is widely used in pharmaceutical, chemical, food, etc. continuous screening of various materials industry, according to user needs can be made into 1-4 layers of screen surface.
