XL Series Revolving Granulator (Extruding granulator)
XL Series Revolving Granulator (Extruding granulator)
The machine is mainly suitable for pharmaceutical industry, foodstuff Industry, chemical industry, solid drink industry and so on It can make the stirred raw material granulate the needed granule. Especially, it is suitable for raw materials that have sticky adhesive.
All parts contacted with raw material in this machine are made of stainless steel. Its appearance is beauty and taste and its structure is reasonable. Its efficiency is high and the granule is beauty discharge Is automatic. Therefore it can avoid the damaged conditions caused manual. It is suitable for in line production too.
1. This machine is simple operation, convenient maintenance, easy cleaning, part contacting materials adopts stainless steel material, to ensure the high quality material, color, can choose according to need to sieve tube aperture, and can complete automatic discharging, reducing the particle breakage caused by artificial discharging.
2. Screen and blade and quick disassembly and cleaning.
3. High handling capacity, the grain strength of the production is larger than the swing.
Video
Technical Parameter
| Model | 250 | 300B | 30D | ||||||
| Granulation diameter (mm) | 0.5-2.2 | 0.5-3 | 0.5-6 | ||||||
| Grinding knife size (mm) | 250 | 300 | 30D | ||||||
| Motor power (kw) | 3 | 4 | 7.5-6 | ||||||
| Production capacity (kg / h) | 140-200 | 140-300 | 300-600 | ||||||
| Overall dimension of main engine (L *W * H) (mm) | 700*540*1400 | 800*650*1400 | 1300*800*1200 | ||||||
| Weight (kg) | 350 | 400 | 780 | ||||||
Applications
The machine is the desired machinery in the pharmaceutical, food, instant soluble powder, chemical, solid drinks and other industries.
